IlBagnoAlessi is a bathroom design that has cast its spell over the home design world for years: It is characterized by a timeless form, sparkling imagination, and a hint of eccentricity. This design award-winning ensemble is the creation of Italian designer star, Stefano Giovannoni.

Born in 2002 from the creativity of famous Italian designer Stefano Giovannoni, IlBagnoAlessi is one of Laufen’s most successful collections. Based on 15 years of successful cooperation between Laufen and Alessi, the range is one of the most complete and sustainable ever produced on an industrial scale. The IlBagnoAlessi collection is continuously being enriched with new elements and designs, from countertops and freestanding washbasins to bathtubs, from toilets to the furnishings and accessories made in our world-class SaphirKeramik.

The creative and inspiring IlBagnoAlessi collection is a highly innovative and growing project, which, according to Alberto Alessi, “Stefano was able to freely and adroitly draw from the extensive vocabulary of forms that have been made available to humankind, creating objects that are at once more striking and more human”.

What's Included

• Sink
• Mounting Accessories listed below:
• Plated cover, Part Nr. H891944
• Ceramic valve cover plate, Part Nr. H898182
• Mounting instruction, Part Nr. H893975
• Mounting Set M10 x 140 mm, Part Nr. H899882

Not Included

• Faucet (sold separately)
• Mounting Accessories listed below:
• Siphon D40 chrome, Part Nr. H893979

Features

• Overall dimensions: 62" W x 19 11/16" D x 6 1/2" H
• Inside dimensions: 35 1/16" W x 12 13/16" D
• Basin on the left, shelf on the right
• Laufen Clean Coat special glaze as standard
• Meets or exceeds the following: ASME 112.19.2, cUPC/IAPMO listed
• Limited 5-Year Warranty

Specifications

Technical Drawings

Top View

Front View

Side View

Certifications

Laufen Green Mission

Laufen is committed to protecting the environment, placing great emphasis on sustainable manufacturing processes in regard to energy, water and materials uses. Laufen implores efficient and eco-friendly practices across all stages of production – from product development to marketing materials. For example, Laufen uses the waste heat generated in the production process to dry our ceramic pieces.

Laufen’s production sites operate in accordance with strict, international environmental principles. The Swiss Agency for Efficient Energy Use has awarded Keramik Laufen AG its prestigious label for being actively involved in voluntary climate protection. Additionally, Laufen Austria AG- with its production sites at Wilhemsburg and Gmunden- was awarded the EMAS environmental prize for outstanding environmental performance. Overall, Laufen supports and promotes active environmental policies; policies that are embedded in the company’s principles and upheld by our workforce around the world.

cUPC/ASME Compliant

The Uniform Plumbing Code (cUPC) and American Society of Mechanical Engineers (ASME) are trade organizations that cooperatively meet to create mechanical design and test routines for plumbing products. These are trade organizations tasked with creating guidelines for safe and interchangeable products that provide value for consumers and competition among manufacturers. All of Laufen Bathroom ceramic products (unless noted otherwise) meet the design requirements and laboratory testing demands of these organizations. Organizations that provide this testing routine include the International Association of Plumbing and Mechanical Officials (IAPMO Group), which has issued several of Laufen’s certifications.

Laufen Clean Coat (LCC)

The Laufen Clean Coat (LCC) logo can be seen on the Alessi One bathroom collections. LCC is one of the most groundbreaking ceramic finishes on the market; it is virtually poreless and smooth to the touch. This sophisticated ceramic finish ensures that particles of dirt and bacteria can be simply rinsed off with water, thus, the ceramic stays clear of debris and is easier to clean. Due to the glaze-in-glaze method, where the LCC glaze is directly melted with the ceramic, the smooth finish of LCC remains hard and robust.

Warranty

	Laufen branded ceramic products and all bathtubs (acrylic, Santec, Marbond) are warranted against defects in material and/or workmanship for a period of five (5) years from the date of original purchase.
	Furniture items including vanities, wall cabinets, and related accessories are warranted against defects in material and workmanship for a period of one (1) year from the date of original purchase.
	Components such as bolts, fill and flush valves, drains, and seats with covers are warranted against defects in material and workmanship for a period of one (1) year from the date of original purchase.

Documents & Files

• Technical Fact Sheet
• Parts List & Assembly Procedure
• Technical Drawings
• CAD 2D F - H814971
• CAD 2D S - H814971
• CAD 2D T - H814971
• CAD 3D - H814971
• BIM 2D - H814971
• BIM 3ds Max - H814971
• BIM ArchiCAD - H814971
• BIM AutoCAD - H814971
• BIM ifc - H814971
• BIM Revit - H814971
• BIM SketchUp Model - H814971
• Special Features
• Warranty

Designer: Stefano Giovanni

Stefano Giovannoni’s expressive designs skilfully play with the symbols and metaphors of the sub-conscious and their narrative qualities are fascinating. The brands Stefano Giovannoni works with include Alessi, Flos, Helit, Inda, Laufen, Magis, Oras, Seiko, 3M and many others. Not only does he design industrial products in the fields of kitchen, bathroom, furniture, the home, cars and electronics, he also designs interiors and architecture. His work is part of the permanent archive at the Georges Pompidou Centre in Paris and at the collection of the Museum of Modern Art in New York.

Stefano Giovannoni was born in 1954 in La Spezia and studied architecture in Florence. Today he lives and works in Studio Giovannoni, a restored old factory area in Milan city centre. With "IlBagnoAlessi One" he has placed one of the most remarkable bathroom designs of recent years on the market. The Tam-Tam floorstanding washbasin, with its rounded, soft shape which highlights the organic aspect of the bathroom, received a Design Plus award and is the visual anchor and determining design feature of the bathroom, which is a cooperative venture between Alessi, Laufen and Oras. In 2010 Giovannoni has again been commissioned with the creation of a comprehensive extension of IlBagnoAlessi One, which was presented with the Good Design Award 2011. In 2014 additional new objects for the popular collection followed, including for the first time accessories made of the revolutionary SaphirKeramik of Laufen.

Designer Stefano Giovannoni: “Immediately I started work on the Alessi bathroom project I quickly realised that the tub and ceramic components symbolise the nurturing aspect in bathrooms – the feminine world – curvaceous and soft. I tried to use this symbol in various features of the bathroom: This is obvious in the case of the ceramics, which are always pretty close to this archetypal symbol”.
