Mesa 45" x 35" x 85" Blue Tempered Glass Freestanding Walk In Steam Shower With Left-Hand Control Panel Configuration, 3kW Steam Generator and 6 Acupuncture Water Body Jets

Mesa 45" x 35" x 85" Blue Tempered Glass Freestanding Walk In Steam Shower With Left-Hand Control Panel Configuration, 3kW Steam Generator and 6 Acupuncture Water Body Jets

5 reviews
Regular price $2,596.00
Regular price $3,894.00 Sale price $2,596.00
Sale Sold out
  • Free Shipping on Orders Over $300
  • Same-Day Order Processing
  • Easy Monthly Installments Starting at 0% APR*
Got a question?
• Text or call 800-614-7411
• Email support@usbathstore.com
• Start a live chat

Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.

The Mesa WS-802L steam shower has tempered blue glass and a nickel interior control panel. Available as both a left and right-side unit, the WS-802L is a perfect steam shower for smaller bathrooms. It features chrome columns and hardware, a sliding glass door, and a fold-up seat for additional space. The sleek design and slightly curved front add style and modern flair to any bathroom.

What's Included

Features

  • Left-Hand Control Panel Configuration
  • 3kW Steam Generator
  • 6 Acupuncture Water Body Jets
  • Adjustable Handheld Shower Head
  • Rainfall Shower Head
  • FM Radio Built-In
  • Tempered Blue Glass
  • Ozone Sterilization System
  • Storage Shelves
  • Blue LED Lighting
  • Tempered Blue Glass
  • Foldable Corner Seat
  • Ventilation Fan
  • Towel Bar
  • Flexible Drain Hose: You can pretty much put your drain anywhere you want.  All Mesa units come with a pre-cut drain and flexible hose.  This means you are now able to put your drain or steam shower anywhere you want!!
    Click here for details...

    Mesa's Flexible Drain Hose

    Mesa Steam Showers, bathtubs, and whirlpools include a flexible drain hose for fast easy installation. Mesa includes a flexible drain hose to help you get the job done faster and easier, with professional-grade durability and more versatility than a traditional corrugated pipe. Flexible and expandable, it easily bends around any obstacle, holds its shape during installation and with a simple snap, its integrated soil-tight fittings lock securely and stay connected during backfilling.

Specifications

Electrical

    • ETL Certified
    • 3000W Steam Generator
    • 220v ETL Approved (Standard)
    • 12v Lighting
    • 20 AMP Dual Pole Breaker

    Plumbing

      • Hot/Cold Connection – ½” Faucet Lines
      • Flexible Hoses

      Drainage System

        • 1 ½” Drain Intake
        • 1 ½” Flexible Drain Hose

          Dimensions

          • 45" W x 35" D x 85" H (add 2" for ventilation exhaust pipe)

          Warranty

          All steam showers carry a (7) seven-year structural warranty against manufacturer defects. The structural warranty protects the structure of the steam shower from peeling, fading, delaminating, or cracking. Structural components include acrylic panels, shower pan, ceiling, and glass panels.

          All steam shower parts carry a (1) one-year guarantee against defects.

          Mesa Steam Showers recommends that a certified plumber or electrician replace the spare part. Mesa Steam Showers does not accept any responsibility or liability for the installation of spare parts.

          Documents & Files

          Videos

          Frequently Asked Questions

          Does the unit come in one piece or in panels?



          All units come in panels. The great thing about our Stand Alone Steam Showers is that they are pre-assembled with pre-drilled holes. You can move any of the units through a standard 32" doorway for easy access into remodeled homes, basements, and other unique situations.
          Can I fit the parts through a standard doorway?



          Yes, all units can fit through a standard 32" doorway. Even units with a whirlpool tub will fit through any space larger than 26".
          What type of Electrical Connection and Breaker will I need?



          220v with a 20amp dual pole breaker GFCI Breaker for the steam shower.
          I would like to place on the second floor, will there be a weight problem?



          The unit is about 500 lbs.+water and your weight, and that is definitely a case by case type question. Please consult your contractor based off of these weights we have provided.
          What does the inline heat pump do?



          The inline Heat Pump is attached to the water pump, and the heat pump will maintain the water temperature in the tub portion of the unit.
          How many HOT/COLD Connections are required?



          Regardless of the number of showerheads, all units have one hot/cold connection.
          Where is the HOT/COLD Connection located?



          The connection is located behind the shower hot/cold controls which differs per unit. Normally the hot/cold is about 30" from the the floor on the back of the unit. Flex hoses are included for easy hook ups no matter where your current hot/cold is located.
          Where is the steam generator located?



          The steam generator is located underneath the tub and on certain units, it is placed on the back of the unit. All generators are mounted to the frame or screwed to the back of the unit so that they do not take up an room beyond the dimensions of the shower. All of the steam showers will sit flush against the wall.
          Do I need an access panel?



          The steam showers are designed to be free standing units so that in case of an issue behind the unit, you can easily slide the unit away from the wall for access. The plumbing and the electrical connections are flexible so that you can easily make this happen. If at all possible, an access panel is a terrific option in case of any future issues.
          View full details
          Customer Reviews
          5.0 Based on 5 Reviews
          5 ★
          100%
          5
          4 ★
          0%
          0
          3 ★
          0%
          0
          2 ★
          0%
          0
          1 ★
          0%
          0
          Write a Review

          Thank you for submitting a review!

          Your input is very much appreciated. Share it with your friends so they can enjoy it too!

          Filter Reviews:
          MG
          05/04/2021
          Maverick G.

          Nice unit

          I install this steam unit my self, I�m a home builder and very capable to handle a project like this, it took eight hours that does my include unpacking the unit. I advise anyone trying to do this them selves is to look up the steam shower you bought on the internet and find instructions �video with no words �on how to assemble your unit. The instructions that come with the unit is not very informative. If your a novice you might consider hiring someone qualified. Now that my unit is in operation I really in joy it. Good purchase and product for the money.

          ZA
          04/18/2021
          Zain A.

          Wow

          This shower took a long time to get. But what can you expect from Covid. Right? This showers installation schematics **** at best but I had put one together similar to this before so I at least had a clue. I wish the drain hose was more flexible. What a pain it was. There are 2 videos on You-tube that can help. We got it altogether and wished the door opening was a little bigger. But still acceptable. Love the color and electronics. Steam generator is phenomenal. All in all, I would buy another. Please work on installation instructions. They still need improvement.

          OF
          01/19/2020
          Omari F.

          Nice shower

          Great price, cool design. This shower is probably the best fit for a medium-sized bathroom. As far as installation you can do it your self but I would recommend having prior experience with electrical and plumbing.

          SW
          12/31/2019
          Shaun W.
          HR
          02/18/2019
          Holly R.

          Fast shipping and easy delivery. Our plumber put it together in a few hours. We were able to use the steam the same day. Works just like a normal shower with lots of other cool features like the FM radio, body sprays and steam. My husband likes the rainfall shower the best.
