SKU:05C1AF0A000
MrSteam e-SERIES MS90EC1 5 kW Steam Generator Incl iSteam Control With iButler Package
MrSteam e-SERIES MS90EC1 5 kW Steam Generator Incl iSteam Control With iButler Package
- Free Shipping on Orders Over $300
- Same-Day Order Processing
- Easy Monthly Installments Starting at 0% APR*
• Text or call 800-614-7411
• Email support@usbathstore.com
• Start a live chat
Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.
"MAKING STEAM SINCE 1917"
This all-in-one, the ready-to-install package gives you everything you need to create your own fully functional steam shower system at home, and at a substantial discount. The iButler® ® Package features the award-winning isteam® 3™ Control, the most technologically advanced steam shower control available. Housed in a sleek, slimline package it mounts nearly flush. The capacitive touch screen is so technologically advanced it can tell the difference between a drop of water and your finger.
Only with the isteam® 3™ can you add ChromaSteam® 3 Mood Lighting System and AudioSteam® 3 Music System. Complete the experience by adding the AromaSteam System. The iButler® ® Package combines the isteam® 3™ control with a matching Aroma Glass SteamHead in black or white glass face, the SteamLinx Mobile App, AutoFlush® ® System, a condensation pan, and a Steam Generator. One selection and you’re ready to bring serenity and wellness into your home.
What's Included
- Generator (MS90EC1)
- iSteam Control Black or White (ISTEAM3-BK or ISTEAM3-WH)
- AutoFlush (MS81500E)
- Condensation Pan (103867)
- SteamLinx (STEAMLINX)
- SteamHead (104104BK-PC or 104104WH-PC)
- Installation Manual
Steam Installation & Planning
What Exactly Is A Steam Shower?
A steam shower heats water until it vaporizes and then pumps that delicious steam into an enclosed area for your enjoyment. It’s a simple idea—but doing it efficiently, reliably, and beautifully is an art and a science that we’ve spent decades mastering. Click on the components below for an explanation of how a steam shower system operates.
Benefits Of Steam
Wellness starts with MrSteam®
Nature’s oldest therapy is a key to living well. The innovative steam therapies have been shown to improve physical and mental well-being.
Wellness starts with MrSteam®
Let’s Do Steam Properly
Choosing The Right Components For Your Steam Shower
e-SERIES Steam Generator
The Heart Of Our Intelligent Steam Shower
The Intelligent Steambath®
E-Series Generators are crafted from recyclable stainless steel and assembled with meticulous attention to detail. Designed, engineered and assembled in Long Island City, NY to the most exacting standards, our generators are clean, green, virtually silent, and ultra-efficient.
Mr.Steam Standard Features
- Stainless steel tank
- Industrial, large diameter, serviceable heating element
- Modular Plug and Play connections
- Electronic water-level control system
- Full-port drain valve
- Limited lifetime generator parts warranty
Safety Features
- Built-in, low-voltage 24-volt control
- ASME safety valve
- 60-minute electronic countdown shutdown with 75-minute limiting safety back-up
Steam Generator Features
Install Up To 60 Ft Away Installs in areas such as a cabinet, closet, under a sealed bench or in an insulated attic. |
|
Steam IQ Exclusive microprocessor operating system is the brains of our intelligent steam generator. |
|
Plug & Play Steam Shower Accessories Easily install spa therapy accessories or components such as AromaTherapy, ChromaTherapy, SteamLinx, and more. |
|
Self-Diagnostics LED indicators to help you troubleshoot any connection and maintenance challenges. |
|
Built With Surgical Stainless Steel Naturally corrosion-resistant, 100 percent recyclable stainless steel inside and out. |
|
Easy On The Environment Designed to save water and energy. Uses less than two gallons of water vs 40 gallons for an ordinary bath. |
|
Safety First 60-minute automatic cut-off, low voltage board, designed for easy access and safe service. |
|
Unmatched Quality And Certified For Safety US and Canadian UL listed, and CE and NOM certified for unsurpassed quality and safety. |
|
Industrial Heating Element Reliable, industrial grade and the industry's largest copper heating element heats fast and is easy to remove and service. |
|
One Platform All MS Generators work with all MrSteam Controls and with the SteamLinx Mobile App. |
|
Whisper Quiet Our water solenoid technology ensures that the generator is whisper-quiet and never hammers or hums. |
|
Small Footprint Compact, easy to install, and about the size of a large briefcase. Requires zero clearance, so it can be placed flush against the wall. |
|
AutoSteam Maintains constant steam by introducing just the right amount of water through a proprietary dispersal chamber AutoSteam. |
Technical Specifications Diagram
Steam installation & planning
Steam Generator 360 View
Steam Generator Video
iButler Package
For Total Steam Shower Control
Featuring the iSteam3, MrSteam's most advanced control
Install. Touch. Relax. The Most Sophisticated Butler since Jeeves. What sets iButler apart is that it features the most advanced control we offer, the iSteam3 Sleek and slimline, mounting nearly flush on the wall of your shower, the iSteam3 gives you total control over every detail of your steaming experience.
iSteam® Control
The Steam Control You Install. Touch. Relax.
Total Control of Your Steaming Experience.
Sophisticated and Intuitive. With the iSteam3 you have total control of every detail of your steaming experience. Housed in a sleek, slimline package, it mounts nearly flush on the wall of your shower.
Enhancing The Steam Shower Experience
This award-winning control is the most technologically advanced steam shower control available. It works with all e-SERIES Generators and the SteamLinx App. Built to IP67 specifications, it is capable of full water immersion in up to three feet of water.
|
|
White Color |
Black Color
|
iSteam® Control Video
Aroma Glass® Steamhead
Steamheads That Match Your Bathroom Decor.
Suffuse Your Steam Shower with Aroma
Available in black or white, the glass fascia complements any bath décor and perfectly matches MrSteam glass face controls. The SteamHead also features an oil reservoir discreetly hidden at the top of the steam head. Add a few drops of essential oil to suffuse your steam shower with natural aromas.
Available in Black & White color
Click Here To See About The AromaSteam Steamhead Features
|
A SteamTherapy Bonus
More than Steam - Wellspring of Health. The sleek and integrated oil well is designed to infuse steam with your essential oils— enhancing your steam experience through aromatherapy. The AromaSteam SteamHead goes above and beyond to make sure your steam experience is fully realized.
Aroma Glass® Steamhead Video
SteamLinx® Module
Start Your Steam Shower From Anywhere In Your Home
SteamLinx gives you the convenience of controlling your steam shower from anywhere using a smartphone or mobile device. Start your steam shower, adjust the temperature, duration and stop it with a tap. When you enable the SteamLinx skill for Alexa, you can just ask Amazon Alexa. Compatible with MS Generators serial numbers 1174000 and higher.
SteamLinx, a revolution in controlling steam room functionality remotely. Start your steam session anytime, anywhere—from your bed, your backyard, or even while you are still on your way home. Your steam shower will be ready when you are.
SteamLinx® Module Video
AutoFlush® Self-Cleaning System
Clean Steam... Every Time®
Clean Steam Without Lifting a Finger
Your steam generator is the most important component of your steam shower. Protect your investment with AutoFlush. AutoFlush is a MrSteam exclusive product. It’s an automatic self-cleaning system that promotes a long, healthy life for steam generators by automatically flushing the generator of sediment two hours after every steambath.
We automate everything in the background, so no work is needed after every steam shower session. AutoFlush assures that you get clean steam every time.
AutoFlush® Video
Mr.Steam Condensation Pan
Prevents Water Spillage From The Generator
Protects against potential water leaks
Sitting under our e-SERIES Generators, the Condensation Pan protects from potential water escape. Just locate the condensation pan on a solid level surface and place the steam generator inside the condensation pan. Ensure the steam generator is level as the condensation pan drains by gravity.
Mr.Steam strongly recommends the use of a condensation pan in the unlikely event of a plumbing leak.
- ◄Click here to know more about the Condensation Pan
-
Specifications
- Pairs with e-SERIES MrSteam generators
- 25” x 9” x 1 ½” (L x W x H)
Steam Installation & Planning
Important Note
All plumbing shall be performed by a qualified licensed plumber and in accordance with applicable national and local codes. Check local plumbing code for receptor, trap, and vent requirements.
Features
- e-SERIES Generators are crafted from recyclable stainless steel and assembled with meticulous attention to detail. Designed, engineered, and assembled in Long Island City, NY to the most exacting standards, our generators are clean, green, virtually silent, and ultra-efficient.
- The award-winning, touchscreen isteam® 3™ allows for control of every detail of your steaming experience and is housed in a sleek, slimline package, that mounts nearly flush on the wall of your shower.
- AutoFlush® ® is an automatic self-cleaning system that promotes long, healthy life for steam generators by automatically flushing the generator of sediment two hours after every steambath.
- The Condensation Pan protects bathrooms from potential water escape and drains by gravity.
- SteamLinx, a revolution in controlling steam room functionality from your smartphone or mobile device, allows you to start your steam session anytime, anywhere—from your bed or even from your backyard.
Product Specifications
Weight | 45lbs |
Width (Side To Side) | 14-1/2" |
Depth (Front To Back) | 6 ¾" |
Height (Top To Bottom) | 14-¾" |
Dimensions | 14-1/2" x 14-¾" x 6 ¾" (W x H x D) |
Shipping Dimensions | 33" x 13" x 22" (W x D x H) |
Technical Specifications
AMPS | 21 A |
Compatible Genrator | MS90EC1 |
Construction Materials | Stainless Steel |
Control (Adjustable Session?) | Yes |
Control (Adjustable Temperature?) | Yes |
Control Clock | Yes |
Control (Steam Head Included?) | Yes |
Control (Screen Size) | 4" |
Country Of Origin | United States |
Generator (Automatic Shut-Off) |
Yes |
Generator (BTU) |
17061.71 |
Generator (Drain Location) |
Right |
Generator (Drain Opening) |
1/2" NPT |
Generator (End Connection) |
NPT |
Generator (Fuel Type/ Power Option) |
Electric |
Generator (GPC) |
0.67 GAL. PER 20 MIN CYCLE |
Generator (GPM) |
0.031GPM |
Generator (Inlet/ Outlet) |
"3/8"" NPT Water Inlet 1/2"" NPT Steam Outlet" |
Generator (Line Fuse) |
30 |
Generator (Max Room Volume) | 71 Cu. Ft. |
Generator (Maximum Pressure) | 0 PSI |
Generator (Maximum Temperature) | 45°C |
Generator (Maximum Time) | 60 min. |
Generator (MBH) | 17.06 |
Generator Phase | 1 PH |
Generator (Pipe Fitting & Tubing) | 1/2 NPT & 3/8 NPT |
Generator (Steam Production Time) | 15 min. |
Generator (Wire Gauge) | 10 AWG |
Installation Type | Hardwired |
Kilowatts | 5kW |
Watts | 5000W |
VOLTS | 240V |
Uses Electricity? | Yes |
Warranty
Limited Lifetime Warranty for MrSteam Residential Steambath Generator Products Installed in the United States or Canada.
"Mr.Steam® warrants that every Mr.Steam® Residential Steambath Generator (“Generator”) will be free from defects in materials and workmanship for its lifetime. Mr.Steam® will repair or replace (at its option) a Generator that fails to conform to this warranty. If the warranty claim is made within two years from the date of purchase of the Generator, Mr.Steam® will provide free in-home warranty service, parts, and labor. If the warranty claim is made after two years from the date of purchase of the Generator, Mr.Steam® will provide a lifetime warranty on parts.
Mr.Steam will repair or replace (at its option) Mr.Steam Controls and Accessories if they fail to conform to this limited warranty. All warranty work will be performed without charge when the Mr.Steam Control and Accessory are returned to the location designated by Mr.Steam within 2 years of the date of purchase. To obtain warranty service, call 1888-524-3349 or support@usbathstore.com.
Warranty Service within 2 years from the date of purchase
If the warranty claim is made within two years from the date of purchase of the Generator, MrSteam will provide free in-home warranty service, parts, and labor.
Note: If in the judgment of MrSteam the defect is not covered by this warranty, the costs of any in-home service, as well as the costs of repair or replacement together with all freight charges, will be the responsibility of the claimant.
